KJGMaterialsAluminium prepainted W.15Testa di Moro W.15

Aluminium prepainted W.15 – Testa di Moro W.15 RAL 8028

Testa di Moro W.15 8028 - Aluminium prepainted W.15 - Picture

Material structure

Picture - Material structurePicture - Material structure 2
MaterialAluminium prepainted W.15
ColoursTesta di Moro W.15
Colour shortcutTMM
RAL colour8028
Available thicknesses0,70

Material usage

Picture - Half-round gutter systemHalf-round gutter systemPicture - Square gutter systemSquare gutter systemTrough guttersPicture - CoilsCoilsPicture - Roof covering KJG FALZRoof covering KJG FALZ

Material properties

KJG a.s. is a multimetallic company that uses high quality materials for processing. In its portfolio, it has seven basic materials plus painted sheets in more than 40 colour versions. The exclusive suppliers of materials are European companies that meet all the required standards. This guarantees high quality of raw materials and is a prerequisite for high quality standards of KJG a.s.

Aluminium coils and sheets are made of well-formed aluminium alloys. For this reason, aluminium sheets are easily and safely processed. Aluminium sheets are suitable for fold roofs, facade panels, gutter systems, roof covering or windowsills. Aluminium reacts with oxygen in the air, creating a natural layer of oxide. This layer provides excellent protection against corrosion.

Technical sheet

Technical sheetspeira

Suppliers

Picture - speira EN AW 3105 H44 (profiles)EN AW 3005 H41 (coil, sheet)

speira
EN AW 3105 H44 (profiles)
EN AW 3005 H41 (coil, sheet)

Overview of benefits

Recyclability
Colour fastness
Corrosion resistance
High plasticity
From traditional producers
Wide range of use

Overview of properties

Melting point660 °C
Density2,7 kg/dm³
Length change at 100 K2,4 mm/m

Weight of metals for given thicknesses

Material0,50 mm0,55 mm0,60 mm0,65 mm0,70 mm0,80 mm1,00 mm1,50 mm
Picture - Galvanized steelGalvanized steel
3,93 kg/m²4,32 kg/m²4,71 kg/m²5,10 kg/m²5,50 kg/m²6,28 kg/m²7,86 kg/m²11,79 kg/m²
Picture - Galvanized steel prepaintedGalvanized steel prepainted
3,93 kg/m²4,32 kg/m²4,71 kg/m²5,10 kg/m²5,50 kg/m²6,28 kg/m²7,86 kg/m²11,79 kg/m²
Picture - AluminiumAluminium
1,35 kg/m²1,49 kg/m²1,62 kg/m²1,75 kg/m²1,89 kg/m²2,16 kg/m²2,70 kg/m²4,05 kg/m²
Picture - Aluminium prepaintedAluminium prepainted
1,35 kg/m²1,49 kg/m²1,62 kg/m²1,75 kg/m²1,89 kg/m²2,16 kg/m²2,70 kg/m²4,05 kg/m²
Picture - Titanium zincTitanium zinc
3,60 kg/m²3,96 kg/m²4,32 kg/m²4,68 kg/m²5,04 kg/m²5,76 kg/m²7,20 kg/m²10,80 kg/m²
Picture - Titanium zinc PatinaTitanium zinc Patina
3,60 kg/m²3,96 kg/m²4,32 kg/m²4,68 kg/m²5,04 kg/m²5,76 kg/m²7,20 kg/m²10,80 kg/m²
Picture - CopperCopper
4,46 kg/m²4,90 kg/m²5,35 kg/m²5,80 kg/m²6,25 kg/m²7,14 kg/m²8,93 kg/m²13,39 kg/m²
Picture - Copper PatinaCopper Patina
4,46 kg/m²4,90 kg/m²5,35 kg/m²5,80 kg/m²6,25 kg/m²7,14 kg/m²8,93 kg/m²13,39 kg/m²
Picture - Stainless steelStainless steel
3,95 kg/m²4,34 kg/m²4,74 kg/m²5,13 kg/m²5,53 kg/m²6,32 kg/m²7,90 kg/m²11,85 kg/m²

Weights refer to 1 m² of sheet metal

Material thermal expansion of used metals

Temperature10 °C20 °C30 °C40 °C50 °C60 °C70 °C80 °C90 °C100 °C
Picture - Galvanized steelGalvanized steel
0,12 mm/m0,24 mm/m0,36 mm/m0,48 mm/m0,60 mm/m0,72 mm/m0,84 mm/m0,96 mm/m1,08 mm/m1,20 mm/m
Picture - Galvanized steel prepaintedGalvanized steel prepainted
0,12 mm/m0,24 mm/m0,36 mm/m0,48 mm/m0,60 mm/m0,72 mm/m0,84 mm/m0,96 mm/m1,08 mm/m1,20 mm/m
Picture - AluminiumAluminium
0,24 mm/m0,48 mm/m0,72 mm/m0,96 mm/m1,20 mm/m1,44 mm/m1,68 mm/m1,92 mm/m2,16 mm/m2,40 mm/m
Picture - Aluminium prepaintedAluminium prepainted
0,24 mm/m0,48 mm/m0,72 mm/m0,96 mm/m1,20 mm/m1,44 mm/m1,68 mm/m1,92 mm/m2,16 mm/m2,40 mm/m
Picture - Titanium zincTitanium zinc
0,22 mm/m0,44 mm/m0,66 mm/m0,88 mm/m1,10 mm/m1,32 mm/m1,54 mm/m1,76 mm/m1,98 mm/m2,20 mm/m
Picture - Titanium zinc PatinaTitanium zinc Patina
0,22 mm/m0,44 mm/m0,66 mm/m0,88 mm/m1,10 mm/m1,32 mm/m1,54 mm/m1,76 mm/m1,98 mm/m2,20 mm/m
Picture - CopperCopper
0,17 mm/m0,34 mm/m0,51 mm/m0,68 mm/m0,85 mm/m1,02 mm/m1,19 mm/m1,36 mm/m1,53 mm/m1,70 mm/m
Picture - Copper PatinaCopper Patina
0,17 mm/m0,34 mm/m0,51 mm/m0,68 mm/m0,85 mm/m1,02 mm/m1,19 mm/m1,36 mm/m1,53 mm/m1,70 mm/m
Picture - Stainless steelStainless steel
0,16 mm/m0,32 mm/m0,48 mm/m0,64 mm/m0,80 mm/m0,96 mm/m1,12 mm/m1,28 mm/m1,44 mm/m1,60 mm/m

Material expansion is given in millimetres per meter, the temperature is in degrees Celsius

Metals you can use together for construction

MaterialGalvanized steelGalvanized steel prepaintedAluminiumAluminium prepaintedTitanium zincTitanium zinc PatinaCopperCopper PatinaStainless steel
Picture - Galvanized steelGalvanized steel
Picture - Galvanized steel prepaintedGalvanized steel prepainted
Picture - AluminiumAluminium
Picture - Aluminium prepaintedAluminium prepainted
Picture - Titanium zincTitanium zinc
Picture - Titanium zinc PatinaTitanium zinc Patina
Picture - CopperCopper
Picture - Copper PatinaCopper Patina
Picture - Stainless steelStainless steel
connection possible
connection not possible

Similar colours/surfaces

Anthracite W.15 7016 - Picture

Anthracite W.15

RAL 7016

Mouse grey W.15 7005 - Picture

Mouse grey W.15

RAL 7005

Intense black W.15 9005 - Picture

Intense black W.15

RAL 9005

Steel red W.15 3009 - Picture

Steel red W.15

RAL 3009

Brown grey W.15 7013 - Picture

Brown grey W.15

RAL 7013

White aluminum W.15 9006 - Picture

White aluminum W.15

RAL 9006

Pure white W.15 9010 - Picture

Pure white W.15

RAL 9010

Zinc grey W.15 extra - Picture

Zinc grey W.15

RAL extra

Copper brown W.15 8004 - Picture

Copper brown W.15

RAL 8004

Moss green W.15 6005 - Picture

Moss green W.15

RAL 6005

Grey aluminum W.15 9007 - Picture

Grey aluminum W.15

RAL 9007
